Load-sensing AutoShift powertrain technology eliminates productivity-interrupting manual shifts between gear ranges while providing smooth direction changes.
With a standard top speed of over 23 mph, the 244 P-Tier can make some pretty quick moves on and between jobsites.
Loader arm and coupler design improves the lifting path to near parallel — for better load-carrying capability than previous models. This keeps the load more level from ground to truck-bed height and helps the operator focus on the task instead of on making manual adjustments.
Low-effort joystick controls boom and bucket, forward-neutral-reverse (F-N-R), and differential lock. Standard mini-joystick controls auxiliary hydraulic functions including optional high flow. Adjustable-height monitor lets operators keep close watch on vital machine functions.
Standard ride control cushions the boom during travel over rough and uneven terrain, reducing material spillage from the bucket and minimizing site cleanup.
Industry-exclusive Articulation Plus™ steering system combines 30 degrees of articulation with 10 additional degrees of rear-wheel steer. Reduced articulation angle design delivers tighter turns that are more stable, especially with large loads, than comparatively sized loaders without Articulation Plus.
Select a category to view specifications (or view all).
Dimensions
Height - Pivot Pin, mm (ft/in)
3220 (10 ft 7 in)
Height - Over Cab, mm (ft/in)
2750 (9 ft )
Ground clearance, mm (inches)
285 (11)
Wheelbase, mm (ft/in)
2150 (7 ft 1 in)
Reach - At 2130mm 45° Dump, mm (ft/in)
1520 (5 ft )
Width Over tires - Std, mm (ft/in)
1920 (6 ft 4 in)
Capacities
Fuel Tank, ltr (gallons (US))
90 (23.8)
Breakout - Bucket, kgf (lbf)
4895 (10792)
Pump Flow - 1, lt/min (gallons (US) / min)
70 (18)
System Pressure, bar (PSI)
230 (3335)
Hydraulic Tank, ltr (gallons (US))
66 (17.4)
Heaped Capacity, m³ (yd³)
0.8 (1)
Ride Control System
Yes
Pump Type
Gear
Driveline
Engine Output - Net, kW (hp)
52 (71)
Tire size - Standard
365 / 70 R18
Front Differential Type
Locking
Engine Manufacturer
Yanmar
Torque, Nm (lbf / ft)
280 (206)
Service Brake - Type
Wet Disc & Drum
Service Brake - Actuation
Hydraulic
Parking Brake - Type
Wet Disc
Engine Model
4TNV98CT
Rated Speed, rpm
2400
Rear Differential Type
Open
Transmission Type
Hydrostatic
Displacement, ltr (Inches³)
3.3 (203)
Weights
Operating Weight, kg (lbs)
5560 (12258)
Features
Operating Weight: 5,560 kg (12,258 lb.)
Cab Height: 2.75 m (9 ft. 0 in.)
Engine Net Power: 52 kW (71 hp)
Bucket Capacity: 0.8–1.1 m3 (1.0–1.4 cu. yd.)
Loan Calculator
Description
Smooth Moves
Load-sensing AutoShift powertrain technology eliminates productivity-interrupting manual shifts between gear ranges while providing smooth direction changes.
Fast Getaway
With a standard top speed of over 23 mph, the 244 P-Tier can make some pretty quick moves on and between jobsites.
On the Level
Loader arm and coupler design improves the lifting path to near parallel — for better load-carrying capability than previous models. This keeps the load more level from ground to truck-bed height and helps the operator focus on the task instead of on making manual adjustments.
Control and Command
Low-effort joystick controls boom and bucket, forward-neutral-reverse (F-N-R), and differential lock. Standard mini-joystick controls auxiliary hydraulic functions including optional high flow. Adjustable-height monitor lets operators keep close watch on vital machine functions.
Enjoy the Ride
Standard ride control cushions the boom during travel over rough and uneven terrain, reducing material spillage from the bucket and minimizing site cleanup.
Turn Things Around
Industry-exclusive Articulation Plus™ steering system combines 30 degrees of articulation with 10 additional degrees of rear-wheel steer. Reduced articulation angle design delivers tighter turns that are more stable, especially with large loads, than comparatively sized loaders without Articulation Plus.
